.085 in. (2.16mm)
Density
Miniature Ribbon
IDC, SUPERIBBON TM
All-Plastic
■
■
■
■
■
■
■
■
■
■
Patented contact terminates Discrete Wire (loose or jacketed cable) without stripping or
soldering solid- and stranded-wire versions available.
All-plastic design reduces cost.
Available in plug and socket styles in 14, 24, 36, 50, and 64 position sizes.
Includes InstaLatch passive latch feature for automatic latching. Sockets are also available
without latches.
Available with .125" or #4-40 mounting holes. 50-position size plug also available to lock with
industry-standard Bail Latches.
Designed for panel mount, 180° (Top-Entry), or 90° (Standard) / 270° (Reverse) End-Entry
cable application.
I ntegral Cable Clamp on End-Entry versions provides superior strain relief, even with
hood removed.
Full range of application tooling is available for termination, unlatching, etc. See page 6-54
for details.
UL Recognized - Files E170218 (UL1977), E130965 (UL1863).
CSA Approved - File LR31996-7.
Insulator: Gray UL94V-0 rated glass-filled polyester, except where noted
Contact: Copper alloy
Contact Plating: select gold over 50μin. select nickel standard;
30μin. select gold over 50μin. select nickel available
where indicated
Operating Temperature: -40°C to +105°C
Shock: 50G Peak, per EIA Std. RS364, TP27, Condition A
Vibration: 3 cycles @ 10-55Hz in each of 3 axes per EIA Std. 364, TP28,
Condition A
Moisture Resistance: Per EIA Std. RS364, TP31, Condition B, with Step
7B excluded
Voltage Rating:
Withstanding Voltage:
Contact Rating:
Contact Resistance:
500 VAC @ sea level; 125 VAC @ 70,000 ft.
1200 VAC RMS @ sea level, per EIA Std. RS364, TP20
5 Amps (4 Amps per CSA)
6 milliohms maximum, per EIA Std. RS364, TP6
Contact Resistance Change During Life Conditioning:
Resistance Change
Wire Size (milliohms, max.)
24 AWG Solid 0.5
26 AWG Solid 0.5
26 AWG Stranded 2.0
28 AWG Stranded 5.0
Insulation Resistance:
5000 Megohms minimum initial;
1000 Megohms minimum after moisture
Call Toll Free: 1 (800) 323-9612
6-6
